Commercial fan CV 160 ERA PRO

Article: CV 160

Design features
Ball-bearing motor
Galvanized steel
Cutout overheating protection
2-year warranty
Ingress protection rating for electrical equipment
Axial fans for supply-exhaust ventilation systems.

Designed for horizontal or vertical mounting directly into the channels or in between the air ducts.

Single-phase induction motor.
Aluminium airfoil impeller.

Galvanized sheet-steel casing.
IPX2 Ingress protection rating for electrical equipment.

CV mounted with VA flexible air ducts and steel hose clamps.

  • Article CV 160
  • Trade mark ERA PRO
  • Material Galvanized steel
  • Color Silver
  • Protection class IPX2
  • Quantity in transport package 1 pieces
  • Height, mm 163
  • Width, mm 163
  • General depth, mm 190
  • Product length, mm 190
  • Installation diameter, mm 163
  • Diameter external, mm 163
  • Internal diameter, mm 158
  • Performance, M3 / H 280
  • Noise level, DB (A) 51
  • Power consumption, w 30
  • Pressure, PA 50
  • Voltage, V. 220
  • Location Channel
  • Working mechanism Axial
  • Principle of ventilation Supply and exhaust
  • Control Mechanical
  • Country of origin Russia
  • Warranty 2 years
