Commercial fan Storm 450 ERA PRO

Article: Storm 450

Design features
Ball-bearing motor
Steel
Mounting with screws
Cutout overheating protection
2-year warranty
Ingress protection rating for electrical equipment
Axial low-pressure fans in steel black polymer-coated casing.
Designed for supply-exhaust ventilation systems and for cooling compression-condensation units.
Works in supply or exhaust mode depending on how it is mounted into the ventilation system.
Induction ball-bearing motors are protected from overheating.
STORM can be equipped with a bipolar or quadrupole induction motor. Configuration depends on the fan size. 200, 250, 300 mm diameter models are equipped with a bipolar motor. 350, 400, 450 mm diameter models are equipped with a quadrupole motor.
Mounted to wall and ceiling surfaces with special square mounting panel (flange).
Equipped with a flange for easy mounting into air ducts of the corresponding size.
IPX4 Ingress protection rating for electrical equipment.
  • Article Storm 450
  • Trade mark ERA PRO
  • Material Steel
  • Color Black
  • Color (decorative) Black
  • Quantity in transport package 1 pieces
  • Height, mm 574
  • Width, mm 574
  • General depth, mm 195
  • Altitude mounting, mm 520
  • Mounting width, mm 520
  • Installation diameter, mm 480
  • Diameter external, mm 450
  • Performance, M3 / H 4800
  • Noise level, DB (A) 64
  • Power consumption, w 315
  • Pressure, PA 120
  • Voltage, V. 220
  • Location Wall-ground
  • Working mechanism Axial
  • Principle of ventilation Supply and exhaust
  • Control Mechanical
  • Country of origin Russia
  • Gross weight, kg 11.2
  • Net weight, kg 9.8
  • Warranty 2 years
