Domestic fan WAVE 100C HT ERA

Article: WAVE 100C HT

Design features
Sleeve-bearing motor
ABS-plastic
Easily detachable face panel
Mounting claws
Mounting with screws
Cutout overheating protection
5-year warranty
Ingress protection rating for electrical equipment
Additional options
Combination of timer and humidity sensor
Back-draught shutter with plastic wings
The WAVE 100C HT exhaust fan is designed for effective ventilation in high-humidity areas such as bathrooms, restrooms, and kitchens. Here are the main features of the model:

- No-drill installation: Thanks to mounting tabs, the fan can be installed without drilling into walls.
- Stylish design: The fan features a closed front panel that is easy to remove for maintenance.
- Low noise level: Only 25 dB(A), comparable to a whisper.
- Durability: The motor with self-lubricating bearings guarantees up to 30,000 hours of operation.
- Humidity control: The fan automatically turns on when the humidity level exceeds 70% and continues to operate until the humidity level normalizes, with the option to set it to 50%, 70%, or 90%.
- Backdraft damper: Prevents unpleasant odors from entering the room from the ventilation duct.
- Color options: Available in black, gray, and ivory finishes.
- Warranty: 5 years.

The model also supports manual control and can operate with a timer, making it a versatile solution for various conditions.
  • Article WAVE 100C HT
  • Trade mark ERA
  • Material ABS plastic
  • Color White
  • Color (decorative) White
  • Protection class IP 24
  • Quantity in transport package 10
  • Height, mm 151
  • Width, mm 151
  • General depth, mm 103
  • Altitude mounting, mm 110
  • Mounting width, mm 110
  • Installation diameter, mm 100
  • Diameter external, mm 100
  • Performance, M3 / H 95
  • Noise level, DB (A) 25
  • Power consumption, w 14
  • Pressure, PA 30
  • Voltage, V. 220
  • Location Wall
  • Working mechanism Axial
  • Principle of ventilation Exhaust
  • Control Automatic
  • Country of origin Russia
  • Gross weight, kg 0.6
  • Net weight, kg 0.5
  • Flange depth 70
  • Check valve depth when closed 6
  • Warranty 5 years
