Article: PACIFIC 150 2SP
The PACIFIC mixed duct fan in a special noise-insulated casing belongs to the quiet fans (noise level from 20 dB(A))* and is designed for premises with high requirements for low noise level. It is used in exhaust ventilation systems in industrial, public and residential buildings when there is a lack of natural draught, as well as for fresh air supply.
The PACIFIC with its mixed impeller and two-speed single-phase ball bearing motor combines the advantages of centrifugal (high pressure) and axial (high airflow) fans.
Lightweight and durable polypropylene foam housing with noise-absorbing inserts eliminates vibrations transmitted from the fan to the ducts, reducing fan noise.
Mounting is carried out without additional brackets thanks to the metal rail. Installation is possible on both horizontal and vertical planes.
Stamped galvanized steel flanges with rubber seals simplify installation into the duct system.
Lifespan: 5 years
Capacity: from 180 to 1560 m³/h
Operating temperature: from - 20 to +40 °С
Ingress protection rating for electrical equipment is IPX4
* among commercial fans manufactured by ERA Group
